Brief Introduce :

Model LBZ-LS Corrugated Out-Sleeve Forming Machine is a advanced machine developed on the LBZ-LS double walls paper cup machine. In this machine, the out sleeve layer are corrugated paper .
The difference between the LBZ-LS and LBZ-LH model sleeve forming machines : the sleeve feeding device is different, In the LBZ-LS Corrugated out-sleeve forming machine, the feeding device is a mechanical hand .

About the out-sleeve corrugate layer:
The inside layer ( face the inner cup layer) is light PE coated paper (100gsm for example) ;
The outside layer is raw paper(printed) ;
It is easy to finish the corrugated paper on a corrugating machine .

Main Technical Data:

Suitable Paper Bowl Sizes: 6oz--20oz, 20oz--60oz or other sizes
Row material of outside packing: corrugated paper
Ration productivity: 40--50 pcs per minute
Total power: 4 KW
Power source: 380 V,220 V50 HZ,60 HZ or other needed
Whole machine weight: 850 kg
Appearance size(L x W x H): 2450 x 1260 x 2000 mm

Corrugated Sleeve Paper Cups Samples Show: Paper cups with sleeve wrapped

.......>>>>>>More Samles

Specifiction:

Automatic control adopts optically controlled non-contact switch,Micro-controlled transducer,Step-less speed adjustment,
The out-side Jacket(coat) sealing by the ultrasonic system
Automatic Agglutinate the out layer to the paper bowls with mucilage,
Full automatic,
Easy changing molds produce different sizes paper bowls jacket,
Easy operating by operator (one operator is enough),
Easy maintenance with minimum cost,
Cheap operating cost and low investment,
Air compressor is required for this type machine.
